Specifications:
| Color | Wavelength | Power consumption | Angle | Forward Voltage | Luminous Intensity |
| White | 120mW | 45° | 3,0-3,2V | 15.000mcd | |
| Red | 660nm | 120mW | 45° | 2,0-2,2V | 15.000mcd |
| Yellow | 590nm | 105mW | 35° | 2,1-2,4V | 10.000mcd |
| Green | 570nm | 105mW | 30° | 3,0-3,2V | 10.000mcd |
| Blue | 470nm | 200mW | 40° | 3,2-4,0V | 8.000mcd |
Diameter: 5mm
Reverse voltage: 5V
Forward current: 20mA
Peak current: 100mA
Working temperature: -40 to 80 degrees centigrade
Storage temperature: -40 to 85 degrees centigrade
