Product Features
GPS individual or fleet positioning
GSM /GPRS modem supports two frequency bands, i.e.900/1800(850/1900)MHz(options)
High-sensitivity, new workmanship and the most advanced GPSchip
Can accurately position even if with weak signals
Can work effectively in limited space such as remote and narrowplaces in a city
Low energy consumption
Fast signal capturing
Supports single positioning and continuous tracking
Supports alarming and remote monitoring
Supports fast dial button
Supports the location information inquiry by SMS and Internet
May monitor without disturbing the tracked person and realizesreal-time tracking
Can position the holder by call or mobile phone SMS
In emergency, press the SOS button to have an accuratepositioning
Product Specifications
Technical Specifications
GSM module GSM850/1900Hz/900/1800MHz
GPS chip Latest
GPS sensitivity -159dBm
GPS center frequency L1, 1575.42MHz
GPS positioning accuracy 5-25m
GSM positioning accuracy 100-500m
Speed accuracy 0.1 m/s
Time accuracy Synchronous with GPS
Default data WGS-84
Hot start 1s
Warm start 38s
Max. altitude 18000m
Max. speed 515m/s
Gravitational acceleration <4g
Others
Humidity 5%-95%
Dimensions 80*49*16 mm
Voltage Rechargeable 750mAh battery
Power supply DC5V
Standby time >48h
Buttons One SOS emergency button for emergency aid; Call 1,Call2
Receive and Hang up buttons
